Planet Switch L3 managed 46 x Gigabit SFP + 4 x 1 Gigabit/10 SFP+ Uplink + 2 x combo 10/100/1000 / 1/10 an Rack montierbar AC 120/230 V/DC 36 60 V

Planet Switch L3 managed 46 x Gigabit SFP + 4 x 1 Gigabit/10 SFP+ Uplink + 2 x combo 10/100/1000 / 1/10 an Rack montierbar AC 120/230 V/DC 36 60 V

Produktbeschreibung:

48x 100/1000BASE-X mini-GBIC/SFP slots 2x 10/100/1000BASE-T
RJ45 copper ports,
shared with Port-1 to Port-2 4x 10 GBASE-SR/LR SFP+ slots,
compatible with 1000BASE-SX/LX/BX SFP RS-232 RJ45
console interface for switch basic management
and setup  Layer 3 IP Routing Features: IP dynamic
routing protocol supports OSPFv2 Routing interface
provides per VLAN routing mode Supports maximum
128 static routes and route summarization Supports
hardware-based wire-speed VLAN routing  Layer
2 Features: Prevents packet loss with back pressure
(half-duplex) and IEEE 802.3x pause frame flow
control (full-duplex) High performance of Store-and-Forward
architecture and runt/CRC filtering eliminates
erroneous packets to optimize the network bandwidth
Storm Control support Broadcast/Multicast/Unknown
unicast Supports VLAN IEEE 802.1Q tagged VLAN
Up to 255 VLANs groups,
out of 4095 VLAN IDs Supports provider bridging (VLAN Q-in-Q,
IEEE 802.1ad) Private VLAN Edge (PVE) Port Isolation
MAC-based VLAN IP Subnet-based VLAN Protocol-based
VLAN VLAN Translation Voice VLAN GVRP (GARP VLAN
Registration Protocol) Supports Spanning Tree Protocol STP,
IEEE 802.1D Spanning Tree Protocol RSTP, IEEE
802.1w Rapid Spanning Tree Protocol MSTP,
IEEE 802.1s Multiple Spanning Tree Protocol, spanning
tree by VLAN BPDU Guard Supports Link Aggregation
802.3ad Link Aggregation Control Protocol (LACP)
Cisco ether-channel (static trunk) Maximum 26 trunk groups,
up to 16 ports per trunk group Provides port mirror
(many-to-1) Port mirroring to monitor the incoming
or outgoing traffic on a particular port Loop
protection to avoid broadcast loops  Compatible
with Cisco uni-directional link detection(UDLD)
that monitors a link between two switches and
blocks the ports on both ends of the link if the
link fails at any point between the two devices
Supports G.8032 ERPS (Ethernet Ring Protection
Switching)  Quality of Service: Ingress Shaper
and Egress Rate Limit per port bandwidth control
8 priority queues on all switch ports Traffic
classification IEEE 802.1p CoS TOS/DSCP/IP Precedence
of IPv4/IPv6 packets IP TCP/UDP port number Typical
network application Strict priority and Weighted
Round Robin (WRR) CoS policies Supports QoS and
In/Out bandwidth control on each port Traffic
policies on the switch port DSCP remarking  Multicast:
Supports IPv4 IGMP Snooping v1,
v2 and v3 Supports IPv6 MLD Snooping v1 and v2
Querier mode support IPv4 IGMP Snooping port filtering
IPv6 MLD Snooping port filtering Multicast VLAN
Registration (MVR) support Security: Authentication
IEEE 802.1x port-based/MAC-based network access
authentication IEEE 802.1x authentication with
guest VLAN Built-in RADIUS client to cooperate
with the RADIUS servers RADIUS/TACACS+ users access
authentication Guest VLAN assigns clients to a
restricted VLAN with limited services Access Control
List IP-based Access Control List (ACL) MAC-based
Access Control List Source MAC/IP address binding
DHCP Snooping to filter un-trusted DHCP messages
Dynamic ARP Inspection discards ARP packets with
invalid MAC address to IP address binding IP Source
Guard prevents IP spoofing attacks IP address
access management to prevent unauthorized intruder
Management: IPv4 and IPv6 dual stack management
Switch Management Interfaces Web switch management
Console/Telnet Command Line Interface  SNMP v1
and v2c switch management SSHv2,
TLSv1.2 and SNMP v3 secure access SNMP Management
Four RMON groups (history,
statistics, alarms, and events)  SNMP trap for
interface Link Up and Link Down notification IPv6
IP Address/NTP/DNS management BOOTP and DHCP for
IP address assignment System Maintenance Firmware
upload/download via HTTP Reset button for system
reboot or reset to factory default Dual Images
DHCP Relay DHCP Option82 DHCP Server User Privilege
levels control NTP (Network Time Protocol) UPnP
Link Layer Discovery Protocol (LLDP) and LLDP-MED
IEEE 802.3ah OAM Network Diagnostic SFP-DDM (Digital
Diagnostic Monitor) ICMPv6/ICMPv4 Remote Ping
Cable Diagnostic technology provides the mechanism
to detect and report potential cabling issues
SMTP/Syslog remote alarm System Log PLANET NMS
System and Smart Discovery Utility for deployment management

Technische Details:
